Overview
The Siemens QF115AN is a 15 amp, 120 volt, single-pole Class A ground-fault circuit interrupter breaker for compatible Siemens plug-on-neutral load centers. Its plug-on-neutral connection removes the coiled neutral pigtail while providing 5 mA personnel ground-fault protection and a 10 kA interrupting rating.
Key Features
-
Safety: Class A GFCI protection trips on hazardous ground-fault leakage and includes self-test electronics.
-
Installation: Plug-on-neutral construction connects directly to the compatible neutral rail; the load conductor terminates at the breaker lug.
-
Compatibility: Intended only for Siemens load centers specifically listed for plug-on-neutral QPF2N breakers.
-
Performance: Rated 15 A, 1 pole, 120 V AC, and 10 kA interrupting capacity.
Specifications
- Manufacturer part number: QF115AN
- Current rating: 15 A
- Voltage rating: 120 V AC
- Poles / phase: 1 pole / 1 phase
- Protection: Class A GFCI, thermal-magnetic
- Mounting: plug-on neutral
- Wire range: 14–8 AWG copper; 12–8 AWG aluminum
- Temperature calibration: 40°C
- Interrupting rating: 10 kA
Common Applications
- Bathroom, kitchen, garage, laundry, basement, and outdoor branch circuits requiring Class A GFCI protection.
- Residential 15 A circuits in compatible Siemens plug-on-neutral load centers.
- Panel upgrades replacing the exact QF115AN catalog number.
- Locations where a pigtail-free neutral connection simplifies wiring and inspection.
